Description
Idealisk premiumpump där tryckluft inte är ett alternativ. Vi erbjuder allt från mindre enheter till större pumpar med höga flöden och stor oljevolym.
Varumärke och produkt
Larzep – handpumpar
Produkt:
Elektrisk hydraulpump med manuell ventil
Arbetstryck:
700 Bar
Tankvolym:
0,24 -7,5 liter
SINGLE ACTING
Typ | Speeds | Usable oil | Modell | Oil displacement per stroke (cm³) | Pressure rating (bar) | Weight | ||
---|---|---|---|---|---|---|---|---|
S/A | No. | cm³ | LARZEP | 1st Stage | 2nd Stage | 1st Stage | 2nd Stage | kg |
Single Acting | 2 | 280 | W20307 | 7 | 1,0 | 20 | 700 | 5,5 |
Single Acting | 1 | 640 | W10607 | - | 3,2 | - | 700 | 7,3 |
Single Acting | 2 | 640 | W20807 | 13 | 2,8 | 20 | 700 | 8,2 |
Single Acting | 2 | 1.000 | WP21007 | 12 | 2,0 | 50 | 700 | 9,0 |
Single Acting | 1 | 1.400 | W11407 | - | 3,2 | - | 700 | 10,9 |
Single Acting | 2 | 1.800 | W21807 | 13 | 2,8 | 20 | 700 | 11,3 |
Single Acting | 2 | 2.600 | W22607 | 46 | 4,0 | 28 | 700 | 12,7 |
Single Acting | 2 | 4.450 | W24507 | 46 | 4,0 | 28 | 700 | 18,1 |
Single Acting | 2 | 6.500 | W26507 | 126 | 4,9 | 28 | 700 | 20,0 |
DOUBLE ACTING
Typ | Speeds | Usable oil | Model | Oil displacement per stroke (cm³) | Pressure rating (bar) | Weight | ||
---|---|---|---|---|---|---|---|---|
D/A | No. | cm³ | LARZEP | 1st Stage | 2nd Stage | 1st Stage | 2nd Stage | kg |
Double Acting | 2 | 1.000 | XP21007 | 12,0 | 2,0 | 50 | 700 | 9,0 |
Double Acting | 2 | 2.600 | X22607 | 46,0 | 4,0 | 28 | 700 | 14,3 |
Double Acting | 2 | 4.200 | X24307 | 16,5 | 2,8 | 20 | 700 | 23,0 |
Double Acting | 2 | 6.500 | X26507 | 126,0 | 4,9 | 28 | 700 | 20,8 |
